Installation and Mounting
A measuring wire under
tension where opera-
tors are standing can
lead to injuries.
> Danger of damage
to wire and sensor.
Do not twist the
measuring wire.
Fig. 3 WDS-P96-M, dimensions in mm (inches), not to scale
wireSENSOR, Z60-M / P96-M / P115-M / P200-M
M4
2x M4
70 (2.76)
96 (3.78)
ø13 (.51)
4
56 (2.20)
(.16)
81.7 (3.22)
ø10
(.39)
36 (1.42)
ø13
(.51)
4x M4x6
2x slot nuts
set screw
M4
