Delivery
Model
Wire acceleration
Wire retraction force (min)
Wire extension force (max)
Protection class
Vibration
Mechanical shock
Weight
FSO = Full Scale Output
3. Delivery
3.1

Unpacking

Do not unpack the sensor by pulling the wire or wire bolt / clip.
Check for completeness and shipping damages immediately after unpacking.
In case of damage or missing parts, please contact the manufacturer or supplier.
i
Remove shipping protection of measuring wire by qualified personnel only and immediately before mounting.
3.2 Storage
Store only with the transport protection in place.
This prevents the measuring wire being pulled out and accidental is snapping back.
- Temperature: -40 to +80 °C (-40 to +176 °F)
- Humidity: 5 - 95 % (non-condensing)
- Atmospheric pressure
wireSENSOR, Z60-M / P96-M / P115-M / P200-M
WDS- WDS- WDS-
1500- 3000- 5000-P115-
Z60-M P96-M M
10 g 7 g 5 g
3.5 N 5 N 4 N
5.5 N 10 N 16 N
0.3 kg 1.1 kg 1.4 kg
WDS-
WDS-
WDS-
10000-
7500-P115- 15000-
M
P115-M
P115-M
6 g 3 g 3 g
8 N 8 N 8 N
24 N 21 N 25 N
dependent upon encoder
20 g, 20 Hz...2 kHz
50 g, 10 ms
1.9 kg 2.8 kg 3.2 kg
WDS- WDS- WDS-
30000- 40000- 50000-
P200-M P200-M P200-M
12 N 11 N 11 N
22 N 22 N 24 N
9.5 kg 10 kg 11 kg
Page 31
