Installation and Mounting
A measuring wire under
tension where opera-
tors are standing can
lead to injuries.
> Danger of damage
to wire and sensor.
7.5
(.30)
Do not twist the
measuring wire.
10
(.39)
Fig. 2 WDS-Z60-M, dimensions in mm (inches), not to scale
wireSENSOR, Z60-M / P96-M / P115-M / P200-M
55 5 (2.19)
for encoder with synchro flange
68.5 (2.70)
for encoder with clamping flange
10
(.39)
25 (.98)
35 (1.38)
23 (.91)
10.5
25 (.98)
(.41)
