10. Software Installation

WinPower is UPS monitoring software, featuring user-friendly interface to
monitor and control your UPS. This unique software provides complete
power protection for computer system while power failure. With the
software users can monitor any UPS status on the same LAN. Furthermore,
a UPS can provide security protection for more than one computer on the
same LAN at the same time, such as shutting down system in security,
saving application data and shutting down the UPS when power fails.
Software Installation on your PC:
Connected by USB to a PC or notebook, the Software enables
communication between the UPS and the computer. The UPS software
monitors the status of the UPS, shuts down the system before the UPS is
exhausted and can remotely observe the UPS via the Network (enabling
users to manage their system more effectively). Upon AC failure or UPS
battery low, UPS takes all necessary actions without intervention from the
system administrator. In addition to automatic file saving and system
shut-down functions, it can also send warning messages via pager, e-mail
etc.
Use the bundled CD and follow the on-screen instructions to install
•
the software WinPower.
• Enter
511C1-01220-0100-478DF2A
After the software is successfully installed, the communication with
•
UPS has been established and an green icon will appear in the
system tray.
• Double-click the icon to use the monitor software (as above).
the following serial No. to
62
install software:
