Pin # Description
1 UPS Fail
2
Summary Alarm
3
GND
4 Remote Shutdown
5
Common
Fig. 9-1 signal of AS400 interface
I/O Pin #
Output 6
7
Output
8
Input
Input
9
Input
61
Description I/O
Bypass Output
Battery Low Output
UPS ON Output
Line Loss Output
