Do not use the hedge trimmer in the rain or
on wet hedges.
The operator or user is responsible for ac-
cidents or damage to other people or their
property. The manufacturer is not liable
for damages caused by unspecified use or
incorrect operation.
Before use, check that the blades
are sharp. Ensure that the blades
are sharpened whenever blunt, in
order to avoid overstressing of the
machine. Damages caused by cut-
ting with blunt blades are not cov-
ered by the guarantee.

General Description

See the front fold-out page for
illustrations.

Scope of delivery

Unpack the device and check it for com-
pleteness. Dispose of the packaging mate-
rial correctly.
- Electric hedge trimmer
- Blade protection
- Instruction Manual

Overview

1 Impact protection with drill hole
for hanging up the device
2 Cutter bar
3 Hand protection
4 Loop grip with deadman switch
5 Vents
6 On/off switch
8 Grip
9 Mains cable
10 Blade protection

Function Description

The electric hedge trimmer is driven by an
electronic motor. The equipment is double-
insulated for safety and does not require
earthing.
The hedge trimmer is equipped with a dou-
ble-sided safety cutter bar. When cutting,
the blades move backwards and forwards
in linear motion. The impact protection on
the tip of the cutter bar prevents unpleasant
recoils should the trimmer come into con-
tact with walls, fences and so on.
The unit can only be operated with the
deadman switch depressed, in order to
protect the operator. In addition, the hand
guard protects against branches and bri-
ars.
Please note the following descriptions for
the function of the operating components.

Technical Data

Electric Hedge Trimmer ............ FHT 600 E3
Input voltage
rating (U) ................. 230-240 V~, 50 Hz
Input power
(power consumption) (P) ................600 W
Safety class .....................................
Protection category...........................IP20
Cutting rate ............................2800 min
Weight (incl. accessories) ...approx. 4.3 kg
Cutting length ................ approx. 600 mm
Blade length
(incl. impact protection)... approx. 680 mm
Blade gap ....................... approx. 24 mm
Sound pressure level
(L ) .................... 84.0 dB(A), K
pA
Sound power level (L
guaranteed ......................... 100 dB(A)
measured ..... 98.2 dB(A); K
Vibration (a ) at the
h
handle ............2.644 m/s
bow handle .....2.711 m/s
GB IE NI
=3 dB
pA
)
WA
= 1,97 dB
WA
; K=1.5 m/s
2
; K=1.5 m/s
2
II
-1
2
2
5
