SOA heating element –
User manual
heating output regulation
Pressing the button switches on the device,
after which, the element will begin to heat.
By turning itself on and off regularly, the de-
vice regulates the heating output of the ra-
diator to an average temperature, as set by
the user within 30-100% of nominal heating
output of the device. The design of the de-
vice (PTC heating element) protects the user
from harm via burning, by automatically lim-
iting radiator temperature to 60°C, regard-
less of the current setting (provided that the
heat output of the element has been correct-
ly matched with the heat output of the radia-
tor). The design of the device as well as phys-
ical characteristics of heating medium inside
the radiator influence the way in which heat
is distributed throughout radiator – temper-
ature of the pipes at the bottom of the radi-
ator (especially the two located at the very
bottom of it), may be lower than the temper-
ature of the remaining parts of the radiator
— this is a normal phenomenon.
46
Timer button
on/off button
Setting of required heating output:
In order to obtain the required room tem-
perature, please set the right heating level
of the device (buttons / ). It is possible to
set 1 of 5 heating levels: 30-40-60-80-100%
of the nominal heating output. Selection of
every subsequent level is indicated by switch-
ing on subsequent diodes.
TIMER Function
TTIMER function allows programming of
the device to heat for 2 hours with a differ-
ent heat output, for instance in order to dry
a towel. After this period of time the device
automatically returns to the setting from be-
fore the 2-hour dryer activation.
TIMER is turned on by pressing the button
(also when the device is off). The device will
start working with the heat output current-
