Lift the rooftop air conditioning unit onto the roof.
Place the unit on the roof panel and align it with the grooves in the mounting base.
Observe the operating orientation.
Connecting the Rooftop Air Conditioner
1. Connect the rooftop air conditioner to the power supply by attaching the cable
to the cable connector.
2. Gently pull out the filter screen to create a passage for the communication
cable.
3. Route the communication cable through the passage and insert the wire into the
opening.
Stack the duct sections and position them according to the roof thickness:
The duct height shall correspond to the roof height, or refer to the following table
as a guide.
Roof Thickness (mm) Recommended Duct Height (mm)
