10b. Washer
10c. Locknut
10d. Holder
11. Oil dipstick
12. Carburettor
12 a Carburettor screw
12b Choke
12c Fuel valve
13. Belt cover
13a. Screw
13b. V-belt
13c. Set screw
13d. Locknut
13e. Nut
14. Rubber pad
14a. Fastening strip
14b. Screw
14c. Spring washer
15. On/off switch
16. Spark plug
16a. Spark plug connector
16b. Installation spanner
4

Scope of delivery (Fig. 2)

Item QuantityDesignation
1. 1 x Guide handle
10. 1 x Chassis
16b. 1 x Installation spanner
1 x Plate compactor
1 x Operating manual
Enclosed accessories bag:
1a. 2 x Screw (M10x70 mm)
1b. 2 x Washer (M10)
1c. 1 x Locknut (M10)
10a. 2 x Screw (M10x30 mm)
10b. 2 x Washer (M10)
10c. 2 x Locknut (M10)
5

Unpacking

WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
28 | GB
• When ordering please provide our article number as
well as type and year of manufacture for the product.
6

Technical data

Engine / drive
Displacement
Engine output
Fuel content
Engine oil
capacity max.
Eccentric vibration unit
oil capacity
Plate size (L x W)
Centrifugal force
Feed
Vibration frequency
Compaction depth
Max. permissible incli-
nation for the engine
CO output
2
Weight
Subject to technical changes!
Noise and vibration
The noise levels have been determined in accordance
with EN ISO 3744. Total vibration emission values (vector
sum of three directions) determined per EN 500-1.
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
Noise data
Sound pressure level L
Uncertainty K
Sound power level L
Uncertainty K
Vibration parameters (hand/arm vibration)
Vibration a
Uncertainty K
The specified sound levels have been measured in accor-
dance with a standardised test procedure and can be
used to compare different tools with one another.
In addition, these values are suitable for estimating the
stresses for the user resulting from the noise in advance.
www.scheppach.com
HP1900S/
HP1100S
1-cylinder
4-stroke for un-
leaded petrol
196 cm³
4.1 kW
3.6 l
0.6 l
0.08 l
approx. 530 x
370 mm
11000 N
25 m/min
5500 vpm
25 cm
925.8 g/kWh
approx. 57 kg
pA
pA
WA
WA
h
HP2300S/
HP1300S
1-cylinder
4-stroke for un-
leaded petrol
196 cm³
4.1 kW
3.6 l
0.6 l
0.08 l
approx. 540 x
420 mm
13000 N
15 m/min
5500 vpm
30 cm
20° 20°
925.8 g/kWh
approx. 83 kg
84.2 dB
2.34 dB
104.1 dB
2.34 dB
10.8 m/s²
1.5 m/s²
