Explanation of the symbols on the equipment

The use of symbols in this manual is intended to draw your attention to possible risks. The
safety symbols and the explanations that accompany them must be perfectly understood.
The warnings in themselves do not remove the risks and cannot replace correct actions for
preventing accidents.
EN 60974-1
f
1~
1
f
2
U
0
U
1
X
l
2
U
2
l
max
l
eff
IP21S
B
26 | GB
Caution - Read the operating instructions to reduce the risk
of inquiry
European standard for welding sets for manual arc welding
with limited on time.
Single-phase static frequency converter transformer rectifierr
Symbol for manual arc welding with sheathed rod electrodes
Direct current
Suitable for welding with increased electric risk
Power input; phase number, as well as
Alternating current symbol and rated value of the frequency
Rated idling voltage
Mains voltage
On-load factor
Welding current
Welding voltage [V]
Rated maximum mains current
Effective value of the highest line current [A]
Protection type
Insulation class
Caution! Risk of electric shock!
