4 . I O
N I T I A L

4.1 Before Initial Operation

Before initial operation and when in use, the brakes must be applied.
Moving the pump together with the patient is prohibited.
Before initial operation, check the following:
- Mains supply voltage must have the same rating as marked on the type-label.
- Mains power cable and mains plug must not be damaged.
- Mains plug must fit properly in the mains socket.
- Device and its connectors must not have any external damage.
- Suction jars and their lids must not have any cracks, brittle or faulty spots.
- Tubing and tubing connectors must not have any cracks, brittle or faulty spots.
- O-rings on the vacuum connectors of the device, the hydrophobic bacterial filter, jar lid, etc.
must not have any cracks, brittle or faulty spots and must be assembled correctly.
To avoid the risk of electric shock, this equipment must only be connected to a mains
supply with a protective earth ground conductor.
For operation, the device must be positioned so the device can be easily disconnected
from the mains supply with the mains power cable.
If one of the above items is not met, the device must not be operated.

4.2 Connections on the Device and Accessories

Device back side

Ardo medical AG
P E R A T I O N
1
2
3
4
Connector for foot switch (optional)
1
2 Connector for potential equalization
3 Device fuses
4 Connector for mains supply
7 Operating Instructions
Master and Senator
Subject to modifications
