3.2 Symbols on the device and their meaning

Follow the Operating
Instructions
Attention
0
Mains switch OFF
I
Mains switch ON
Applied part Type BF
(patient tubing)
Rating label for device
fuses

3.3 Symbols on the packaging and their meaning

Store in a dry place
Fragile; handle with care
Temperature limits
Humidity limit
Atmospheric pressure limit
Keep away from sunlight

3.4 Hydrophobic Bacterial Filter

The hydrophobic bacterial filter has a filtering capacity of 99.999% for particle sizes up to 3.3μm and
provides effective protection in this range against contamination of the pump unit.
In the event of any overflow of the suction jar with liquid or foam, the hydrophobic material acts as a
blocking filter and immediately blocks the vacuum flow. Any pollution and contamination of the pump unit
is thereby prevented.
Discoloration of the white filter material indicates that the filter has been contaminated with liquid or foam
and must be replaced.
Ardo medical AG
1
1 Filter housing
2 Hydrophobic filter material
2
Consult instructions for use
Connector for
Equalization
Connector for Foot Switch
(optional)
Orange LED indicates the
operating state of the foot
switch (optional)
Control knob for vacuum
regulation
Manufacturer
Medical device
Catalogue number
Serial number
Unique Device Identification
Authorized representative in
the European Community/
European Union
Different languages
6
Potential
Operating Instructions
Master and Senator
Subject to modifications
