4.5 Operation, switching ON the device

The operating position for the user is the front side of the device.
Controls and indications are located on the front side.
For protection against overflow and contamination,
only use the device with hydrophobic bacterial filter from Ardo medical.
Before each use, check and inspect suction jars and lids of suction jars.
Damaged or worn-out suction jars and lids of suction jars must not be used.
In the event of unusual noise from the device, switch OFF the device
and contact Technical Service.
The device is connected to the mains supply.
Switch ON the mains switch; the green indicator lamp in the mains switch must light up
and the pump unit must run audibly.

Switching ON the device and operating with foot switch

The device with foot switch option has a symbol for the foot switch and an orange LED
for the operating state of the foot switch on the front of the device.
The device is connected to the mains supply and the foot switch is connected to the device.
Switch ON the mains switch, the green indicator lamp in the mains switch must light up.
If the LED orange does not light up, the pump unit is switched ON by means of the foot switch.
If the LED orange lights up, the pump unit is switched OFF by means of the foot switch.
1 Foot switch in position ON = LED orange does not light up
2 Foot switch in position OFF = LED orange lights up
Ardo medical AG
1
Mains switch ON / OFF
1
2
Control knob for vacuum regulation
2
1
13
2
