OPERATING INSTRUCTIONS

8.5.0 MASTER/SLAVE COLOUR CONTROL ELEMENT PROGRAMMING

Here you can set to decide whether the control element is used in the
Slave Operation
Selection „SLA", standard setting, with sauna base section as master.
or in the
Single/Master operation
Selection „SIN", without sauna base section
Setting for pure colourLEDcontrol without sauna function
3. Use
4. Use
Programming" (see 8.6 Colour-led/Relay Menu Programming)

8.6.0 COLOUR-LED/RELAY MENU PROGRAMMING

Here you can set whether the menu should be adjusted to control the colour relay module or des
colourLEDmodule.
Difference:
The relay module (not dimmable) has 8 adjustable Colours, das LEDmodul 7 (dimmable).
The setting only becomes effective with the colour control element with the address 0.
2. Change selection with
3. Confirm inputs with
IMPORTANT!
If the control element is used in the slave operation (standard mode), the sauna base section
"must" be started again (briefly isolate mains supply), so that the new control element is
recognised. The participant is recognised when the sauna base section is started .
2 colour control elements must not be connected with the same address.
The sauna- and colour control elements have addresses that are independent of each other.
One sauna control element can therefore have the same address as a colour control element.
WE DO IT FIRST.
or key to change selection
to confirm inputs and jump to the "LED/REL menu
or key
46/52
