OPERATING INSTRUCTIONS
9. Use to change the cycle time.
10. Use the Mode key

8.2.0 PROGRAMMING COLOURS

The coloured lamp mixes the desired chroma from the 4 LED-base colours (Red-Green-Blue-
White). This mix can be programmed. This gives the customer the option of programming his
personal colours behind the colour numbers.
Range of the individual components of the colour is always 0 to 20 (5%steps)
11. On the control element wit the MODE
12. Press
(NB: do not change the colour number in the process!)
13. The programmed RED – portion of the chroma flashes in the display.
14. Changeable with
15. The programmed GREEN – portion of the chroma flashes in the display.
16. Changeable with
17. The programmed BLUE – portion of the chroma flashes in the display.
18. Changeable with
19. The programmed White – portion of the chroma flashes in the display.
20. Changeable with
On completion of all inputs (or time-out), the control is again in "Manual" mode.
WE DO IT FIRST.
to confirm the input and thus leave the programming.
together and simultaneously for approx. 3 sec
and with the MODE
and with the MODE
and with the MODE
and with the MODE
key, go into "Manual" mode.
key, confirm the input
key, confirm the input
key, confirm the input
key, confirm the input
44/52
