4.0.0 COLOUR CONTROL ELEMENT

4.1.0 MODULE DESCRIPTION

Control element is made up of the following Components:
Control element board in flush-mounted box with front panel
Data cable
Fixing material
Display
Symbols (LED's)
Keys

4.2.0 DIMENSIONS / FITTING

L x W x D = 120 x 92 x 44,5 mm; ~200 g without cable
and loose; differences possible depending on
customer finish.
