OPERATING INSTRUCTIONS
Fitting suggestion
Fitting on sauna ceiling not right above the oven. (Max. 110° C glass temperature)
Fitting recess 282 x 282mm or 282 x 536 mm for coloured lamp long; do not enlarge recess, to
ensure fitting is water-tight(!).
Rear free for cooling (max. 30° C ambient temperatur e, NB: 80° C housing temperature is
possible)
4 mounting holes are pre-drilled on the front of the coloured lamp.
However, depending on the sauna design or the weight of the coloured lamp
(approx. 3kg) further fastening measures (e.g. screws from the front, etc.) may be required.
You should also ensure that the coloured lamp is sealed on the sauna ceiling.

6.4.0 TECHNICAL DATA LED COLOURED LAMP

Connection:
Power consumption:
Ambient conditions:
Housing:
Mounting:

7.0.0 FUNCTION DESCRIPTION

The following description gives an overview of the operating options of the software of the LED
power element ASFA22 and colour control element Version 14.

7.1.0 SWITCH ON

If the colour control was switched off, it can be activated by pressing the
The colour control changes into the last activated mode (automatic or manual) and the normal
internal lighting goes out.
WE DO IT FIRST.
At least 5x0.75mm²; with 5m silicone cable
Depending on chroma and brightness see LED power
element ASFA22
Glass surface: max. 110° C outsi de
Rear: max. 30° C ambient temperature
L x W x D = 330 x 310 x 96 mm,
or 564 x 330 x 88 mm
Light-emitting surface = 250 x 250mm; or 250 x 500mm
Size of recess 282 x 282 mm; or 282 x 536 mm
With full timber cabins additional frame into the ceiling
element and make the recess larger accordingly.
As per sauna design or with 4 wood screws onto the
sauna ceiling
41/52
key.
