OPERATING INSTRUCTIONS

6.0.0 LED COLOURED LAMP

6.1.0 MODULE DESCRIPTION

The ABATEC coloured lamp may only be operated with the ABATEC power element ASFA22!
It consists of:
LED board
Housing
Supply cable from the LED power element ASFA22 (5m)
ATTENTION!
Due to the temperature load in the sauna and the high level of brightness, the back wall of the
coloured lamp becomes hot (80° C). The user's attent ion must be drawn to the danger of burns, or
the design must prevent this. Under no circumstances must a burn guard impair the cooling of the
rear. The maximum ambient temperature on the rear must not exceed 30° C.

6.2.0 DIMENSIONS / FITTING Coloured lamp

WE DO IT FIRST.
330,00 mm
330,00 mm
330,00 mm
39/52
