7.4.0 TABLE OF COLOURS

Each colour number is allocated a chroma. (Standard on delivery).
Colour
number
1
2
3
4 Turquoise
5
6
7

7.5.0 CONNECTING SEVERAL LED COLOURED LAMPS

Up to eight LED coloured lamps or up to four coloured lamps long can be controlled via a control
element. To allow this, the power elements are connected to each other via a BUS line and
controlled via the LED coloured light-control element. The LED coloured lamps connected to a
control element can not be individually controlled but only together.
The power elements are built into a splash-proof plastic housing. Four power elements can be
screwed into every housing.

8.0.0 PROGRAMMING FUNCTION

The following points provide information on the programmability of the LED coloured lamp.
These settings are stored in a power failure-proof manner.

8.1.0 PROGRAMMING CYCLE TIME

The coloured lamp automatically changes, with the exception of "Manual" mode, the chroma when
the Cycle time ends. This Cycle time is 5 minutes when delivered. It can be adjusted in minute
steps.
Proceed as follows:
6. On the control element with the MOD
7. Press t
8. The programmed Cycle time in minutes flashes in the display.
WE DO IT FIRST.
Chroma Brightness
Red 20
Gelb 20
Green 20
20
Blue 20
Lila 20
White 20
together and simultaneously for approx. 3 sec.
Red Green
20 0
20 20
0 20
0 20
0 0
18 0
17 20
E key, go into "Automatic-time " mode.
43/52
