OPERATING INSTRUCTIONS

5.3.0 PLUG DESCRIPTION LED POWER ELEMENT

5.4.0 TECHNICAL DATA LED POWER ELEMENT

Supply:
Power consumption:
Ambient conditions:
Housing:
Mounting:
WE DO IT FIRST.
X3
4
3
2
1
X2
6
5
4
3
2
1
X1
3
2
1
3-pin 230V +/-6%; 50Hz; with protective conductor (PE) of
L1 of the sauna control
Depending on chroma and brightness max. 0,16 A eff.
0-50° C, max. 95% rel. F. non- condensing
In the plastic housing of the wave.com4
Screw the 4 mounting holes onto the mounting bolts of
the wave.com4 base plate.
To do so: extend the mounting bolts using the spacer
bolts supplied; fasten with 4 No. M3 screws and spring
rings
Modular Jack 4/4
Earth
CAN-
CAN+
+5V=
Modular Jack 6/6
Earth
Earth
CAN-
CAN+
+12V=
+12V=
Supply 230V~
PE
N
L (230V~)
38/52
