4.4 Rooms with a platform or gallery
>16 m² / >2 m
0,5 0,5
Fig. 15 Rooms with a platform or gallery
Allowed
Not allowed
Note the following for rooms with plat-
forms or galleries (area greater than
16 m , at least 2 m long and wide):
2
f Mount additional device under the
platform/gallery.
EN
EN
1/2 1/2
0,5
Operating Manual: PX-1 - Smoke Alarm Device

5 Installation

The device is held by a magnet carrier at
the installation location. The magnet carri-
er can be mounted by gluing or drilling. To
avoid injuries from improper
installation, the instructions in this manual
must be followed. The general safety regu-
lations should also be observed.
CAUTION
Possible property damage!
Using other fastening material (not
enclosed) or wrong conditions at the
installation location can cause the
device to fall down
f Use only the supplied mounting material
(adhesive pad or screws/dowels).
f Ensure that the installation location
is strong enough, solid, dry, free from
grease, dust and loose paint etc.
f Note that the magnet carrier magneti-
cally attracts only from one side.

5.1 Adhesive mounting

The magnet carrier can be mounted using
adhesive assembly as follows:
