CAUTION
Possible property damage!
The mounting of the device according
to vfdb 14/01 (Q) establishes a
permanent connection between the
magnet carrier and the device. Thus,
a subsequent removal of the device
is prevented. It is difficult to carry out
maintenance. If the device is disassem-
bled, it can cause damage to the device
and the mounting surface.
f Use the additional adhesive film
only to prevent theft.
f Put the device in operation
before attaching the additional
adhesive film.
When performing this type of installation,
proceed as follows:
(1) Mount magnet carrier.
f Observe chapter "Adhesive mounting
according to EN 14604:2005/AC:2008"
on page 46.
(2) Take the device into operation.
EN
EN
Operating Manual: PX-1 - Smoke Alarm Device
f Observe chapter 6 "Putting into
operation" on page 49.
(3) Attach additional adhesive film to
the magnet carrier sheet plate on
the device.
f Remove the protective film from
one side of the adhesive film.
f Place the adhesive sheet on the
magnet carrier sheet plate on the
device and press it on.
f Remove the protective film on the
other side.
(4) Place the device on the magnet
carrier and press it on.
5 The device is mounted on the
magnet carrier.
5.2 Drilling installation
As an alternative to adhesive mounting,
you can also screw the magnet carrier on
the mounting surface. Even with the drill-
ing installation, the adhesive pad must re-
main on the magnet carrier and must not
be removed.
