OPERATING MODE DESCRIPTION
Operating modes:
1. Press and release MODE until you see the
symbol glow for the desired setting
2. Choose Cooling, Dry, Fan Only or Heating.
• Cooling-Cools the room. Press FAN to select
High, Mid or Low. Press the Plus or Minus
button to adjust the temperature.
• Dry-Dries the room. The air conditioner
automatically selects the temperature. The fan
runs on Low speed only.
NOTE: Dry mode should not be used to cool the
room.
• Fan Only-Only the fan runs. Press FAN to
select High, Mid or Low.
• Heating-Heats the room. Press FAN to select
High, Mid or Low. Press the PLUS or MINUS
button to adjust the temperature.
NOTE: Heating is NOT available for cooling only
air conditioner.
Fan Speed
1. Press and release FAN to choose the desired fan
speed.
2. Choose High, Mid or Low.
• High-for maximum fan speed
HIGH
• Mid-for normal fan speed
MID
• Low-for minimum fan speed
LOW
Filter Reset
1. When the Filter Reset indicator light is lit,
remove, clean and replace the air filter. See
"Cleaning the Air Filter."
2. Press and release FILTER button after replacing
the air filter.
NOTE: After 360 hours of fan operating time, the
Filter indicator light will turn on. It will remain on
for 180 hours or until you press FILTER button.
After 180 hours, it will turn off automatically.
Temperature
• Press the PLUS button to raise the temperature.
Press the PLUS button once to increase the set
temperature by 1°C.
• Press the down Adjust button to lower the
temperature. Press the down Adjust button
once to decrease the set temperature by 1ºC,
or press twice to decrease the set temperature
by 2ºC.
NOTES:
• In the Cooling and Heating mode, the
temperature can be set between 18ºC and
32ºC.
• In Fan Only mode, the temperature cannot be
set.
• In Dry mode, press the PLUS/MINUS botton the
set temperature change by 2ºC.
