CHARGING BATTERY
» To charge the battery insert the adaptor pin to jack, jack is locating below the scale. Adaptor simply plug into the mains power. The
scale no needs to be turned on.
» The battery should be charged for 12 hours for full capacity.
» Left side of the display there is an LED to indicate the status of battery charging. When the scale is plugged into the mains power
the internal battery will be recharged. If the LED is green, the battery has a full charge. If it is red, the battery is nearly discharged
and if yellow, the battery is being charged.
» Do not use any other type of power adaptor than the one supplied with the scale.
» Verify that the AC power socket outlet is properly protected.
NOTE: Please charge the battery before using the scale for the first time.
INSTALLATION
» Place the scale on a table.
» Carefully place the pan to the four holes on the top cover
» Adjust the water mark bubble level.
» Connect the adaptor pin to the adaptor jack. Adaptor jack is locating below the right side of the scale.
» Adaptor connects into your AC power socket. Pluggable equipment must be installed near an easily accessible socket outlet with a
protective ground/ earth contact.
» Turn on the power switch. On / Off switch is locating below the right side of the scale. Press switch forward to turn on the scale. If
you want to turn off, press again the switch backward.
» Display will be show the scale capacity and will be starting self checking.
» After self checking, display will be come to normal weighing mode.
» Then you can start your operation
NOTE: Initial Start Up
Warm-up time of 15 minutes stabilizes the measured values after switching on.
5. SCALE, KEYPAD AND DISPLAY DESCRIPTION
SCALE DESCRIPTION
1. ON/OFF switch
2. Adaptor Jack
3. Adjusting feet.
USER MANUAL RTN ENG
1
2
3
4
5
4. Display bracket
5. Function/CAL Switch
6. RS232 output
6
