3. SPECIFICATIONS
4. INSTALLATION
UNPACKING
» Carefully take the balance out of its package, make it sure its not damaged and all accessories are included.
» Remove the Indicator from the carton.
» Remove the protective covering. Store the packaging and to use if you need to transport the scale later.
» Inspect the scale and terminal for damage.
» Make sure all components are included.
ACCESSORIES:
» Balance
» Adaptor
» Pan
» Product manual
LEVEL ADJUSTING
Place the scale on a table.
Check the water mark. If, bubble is not centre adjust the leveling feet until reach centre. Check the level when you change the location.
44
(
dimensions in mm)
240
MODEL
Maximum Capacity (kg)
Readability (g)
Tare Range (kg)
Minimum Weight (g)
Resolution
Stabilization time
Warm up time
Units Of Measure
Interface
Calibration
Display
Housing
Pan Size (mm)
Overall Dimensions (mm)
Gross Weight (kg)
Power supply
Operating Temperature
NOT LEVEL LEVEL
USER MANUAL RTN ENG
RTN-15 RTN-30
6/15 15/30
2/5 5/10
-15 -30
40 100
3000/6000/Dual range
2 segons
10 min.
kg/g
Salida opcional RS232
Externa automática
Pantalla LCD retroiluminada con 6
dígitos de 20 mm
Plástico ABS
240x370
370x360x125
5,8
100/240 V AC 50 Hz Adaptador:
12V/500mA
-10oC +40oC/14oF +140oF
