EEx-godkendelse - 5335A:
KEMA 03ATEX1508 X ..................................
Ex-data:
Signaludgang / forsyning, terminal 1 til 2:
U .................................................................. : ≤ 35 VDC
Følerindgang, terminal 3, 4, 5 og 6:
U ................................................................ : 9,6 VDC
o
I .................................................................. : 28 mA
o
P ................................................................ : 67 mW
o
L ................................................................. : 35 mH
o
C ................................................................ : 3,5 µF
o
EEx- / I.S.-godkendelse - 5335D:
KEMA 03ATEX1537 X ..................................
Max. omgivelsestemp. for T1...T4 .............. 85°C
Max. omgivelsestemp. for T5 og T6 .......... 60°C
ATEX, må anvendes i zone .......................... 0, 1, 2, 20, 21 eller 22
Ex-/ I.S.-data:
Signaludgang / forsyning, terminal 1 til 2:
U ................................................................. : 30 VDC
i
I ................................................................... : 120 mADC
i
P ................................................................. : 0,84 W
i
L .................................................................. : 10 µH
i
C ................................................................. : 1,0 nF
i
Følerindgang, terminal 3, 4, 5 og 6:
U ................................................................ : 9,6 VDC
o
I .................................................................. : 28 mA
o
P ................................................................ : 67 mW
o
L ................................................................. : 35 mH
o
C ................................................................ : 3,5 µF
o
FM, må anvendes i ...................................... IS, Class I, Div. 1, Group A, B, C, D
FM Installation Drawing No. ................ 5300Q502
CSA, må anvendes i .................................... IS, Class I, Div. 1, Group A, B, C, D,
CSA Installation Drawing No. .............. 533XQC03
10
II 3 GD
EEx nA [nL] IIC T4...T6
II 1 GD, T80°C...T105°C
EEx ia IIC T6 / T4
IS, Class I, Zone 0, AEx ia IIC
Ex ia IIC
IS, Class I, Zone 0, AEx ia IIC
Marine-godkendelse:
Det Norske Veritas, Ships & Offshore ......... Standard for Certification No. 2.4
GOST R godkendelse:
VNIIM & VNIIFTRI, Cert. no. ........................ Se www.prelectronics.dk
Overholdte myndighedskrav:
EMC 2004/108/EF ....................................... EN 61326-1
ATEX 94/9/EF .............................................. EN 50014, EN 50020, EN 60079-15,
FM................................................................ 3600, 3611, 3610
CSA, CAN / CSA ......................................... C22.2 No. 157, E60079-11, UL 913
Standard:
EN 50284 og EN 50281-1-1
