EC DECLARATION OF CONFORMITY

As manufacturer
PR electronics A/S
Lerbakken 10
DK-8410 Rønde
hererby declares that the following product:
Type: 5335
Name: 2-Wire transmitter with HART
is in conformity with the following directives and standards:
The EMC Directive 2004/108/EC and later amendments
EN 61326-1 : 2006
For specification of the acceptable EMC performance level, refer to the
electrical specifications for the module.
The ATEX Directive 94/9/EC and later amendments
EN 50014 : 1997 + A1, A2, EN 50020 : 2002,
EN 50281-1-1 : 1998 + A1, EN 50284 : 1999 and
EN 60079-15 : 2003
ATEX certificate: KEMA 03ATEX1508 X (5335A)
ATEX certificate: KEMA 03ATEX1537 X (5335D)
No changes are required to enable compliance with the replacement standards:
EN 60079-0 : 2006, EN 60079-11 : 2007 and
EN 60079-15 : 2005
Notified body
KEMA Quality B.V. (0344)
Utrechtseweg 310, 6812 AR Arnhem
P.O. Box 5185, 6802 ED Arnhem
The Netherlands
Rønde, 3 March 2009
20
®
protocol
Peter Rasmussen
Manufacturer's signature
2-WIRE TRANSMITTER
WITH HART
PRetop 5335
• RTD, TC, Ohm, or mV input
• Extremely high measurement accuracy
®
• HART communication
• Galvanic isolation
• For DIN form B sensor head mounting
Application:
• Linearised temperature measurement with Pt100...Pt1000, Ni100...Ni1000, or
TC sensor.
• Difference or average temperature measurement of 2 resistance or TC sensors.
• Conversion of linear resistance variation to a standard analogue current
signal, for instance from valves or Ohmic level sensors.
• Amplification of a bipolar mV signal to a standard 4...20 mA current signal.
• Connection of up to 15 transmitters to a digital 2-wire signal with HART
communication.

Technical characteristics:

• Within a few seconds the user can program PR5335 to measure temperatures
within all ranges defined by the norms.
• The RTD and resistance inputs have cable compensation for 2-, 3- and 4-wire
connection.
• Continuous check of vital stored data for safety reasons.
• Sensor error detection according to the guidelines in NAMUR NE 89.
Mounting / installation:
• For DIN form B sensor head mounting. In non-hazardous areas the 5335 can
be mounted on a DIN rail with the PR fitting type 8421.
• NB: As Ex barrier for 5335D we recommend 5106B.
®
