Material Savings - Carl Valentin DUOPRINT Kurzanleitung

DuoPrint
Key:
Keyboard layout
Key:
Customized entry
Key:
Password
Key:
Standard label

Material Savings

Keys: , , ,
Ribbon save mode
Key:
Label save mode
Key:
Auto feed delay
Key:
CMI length
90
Selection of region for the desired keyboard layout.
The following possibilities are available: Germany, England, France, Greece, Spain, Sweden
and US.
On: The question referring the customized variable appears once before the print start at the
display.
Auto: The question referring the customized variable appears after every printed layout.
Off: No question appears at the display. In this case the stored default value is printed.
By a password several functions can be blocked, so the user cannot work with them.
On: If a print order is started without previous definition of label, the standard label is printed.
Off: If a print order is started without previous definition of label, an error message appears in
the display.
,
Off: Optimisation off.
Standard: Maximum optimisation performance, i.e. there is no transfer ribbon loss whilst this
setting is used (except for a safety distance of 1 mm so that the print fields are not printed into
one another).
Settings with which this optimisation can no longer be achieved are not permitted.
Dialogue: The printing process is stopped at a suitable position and the printer waits for further
data. As soon as this data is transferred to the printer, the printing process continues.
At the end of a print job, the printer remains in the above position so that a follow-up print job
can be transferred to the printer without any loss of material.
Press the key to stop the print job. In doing so, the remaining labels of the print job are
completed. Blank labels are fed into the printer until the last completed label has passed the
front printhead.
Auto: After an adjustable time which can be set under the menu item Auto feed delay, the
remaining labels between the two printheads are printed.
Off: The print is only stopped after complete printing of all labels. Slow data connections or
labels with a long generating time can lead to a loss of material. In the dispensing modes is
this mode activated automatically.
Setting of time after that the remaining labels between the printheads were automatically
printed.
Value range: 0 to 255 seconds
If the print is stopped at the rear printhead it could come to a small interruption in the printout.
This is shown as a fine white line onto the label. In order to avoid this matter a value for the
minimal retraction
(0 – 1 mm) can be set. At this value the label material is retracted. At the next print start the
free range is overprinted.
English
