General information
The operator should not neglect to carefully read the following
instructions and those of the mainframe HM8001 , to avoid any
operating errors and to be fully acquainted with the module
when later in use.
After unpacking the module, check for any mechanical damage
or loose parts inside. Should there be any transportation
age. inform the supplier immediately and do not put the module
into operation.
This plug-in module is primarily intented for use in conjunction
with the Mainframe HM8001. When incorporating it into other
systems. the module should only be operated with the specified
supply voltages.
Safety
Every module is manufactured and tested for use only with the
mainframe HM 8001 according to IEC 348 Part 1 and la (Safety
requirements for electronic test and measurement equipment).
All case and chassis parts are connected to the safety earth con-
ductor. Corresponding to Safety Class 1 regulations (three-con-
ductor AC power cable). Without an isolating transformer, the
instrument's power cable must be plugged into an approved
three-contact electrical outlet,
trotechnical Commission (IEC) safety standards.
Warning!
Any interruption of the protective
side the instrument or disconnection
earth terminal is likely to make the instrument
Intentional interruption is prohibited.
The istrument must be disconnected and secured against unin-
tentional operation if there is any suggestion that safe operation
is not possible. This may occur:
— if the instrument has visible damage,
— if the instrument has loose parts.
if the instrument does not function,
— after long storage under unfavourable circumstances (e.g.
outdoors or in moist environments),
— after excessive transportation
packaging).
When removing or replacing the metal case, the instrument
must be completely disconnected from the mains supply. If any
measurement or calibration procedures are unavoidable on the
opened-up instrument, these must only be carried out by qual-
ified personnel acquainted with the danger involved.
Symbos As Marked on Equipment
4
DANGER - High voltage
Protective ground (earth) terminal.
ATTENTION — refer to manual.

Operating conditions

The ambient temperature range during operation should be
between +100C and +40 oc and should
+700C during transport or storage. The operational position is
optional, however, the ventilation holes on the FM 8001 and on
the plug-in modules must not be obstructed.
Warranty
Before being shipped, each plug-in module must pass a 24 hour
quality control test.
Provided the instrument has not undergone any modifications
Hameg warrants that all products of its own manufacture con-
form to Hameg specifications and are free from defects in mate-
rial and workmanship when used under normal operating condi-
tions and with the service conditions for Wich they were fur-
nished.
M2
dam-
which meets International Elec-
conductor inside or out-
of the protective
dangerous.
stress (e.g. in poor
not exceed —40 oc or
The obligation of HAMEG hereunder shall expire two (2) years
after delivery and is limited to repairing, or at its option, replacing
without charge, any such product which in Hameg's sole opin-
ion proves to be defective with the scope of this warranty.
This is Hameg's sole warranty with respect to the products deli-
vered hereunder. No statement,
understanding, oral or written,
representative or employee of, which is not contained in thiss
warranty will be binding upon Hameg, unless made in writing
and executed by an authorized
makes no other warranty of any kind whatsoever, expressed or
implied, and all implied warranties of merchantibility and fitness
for a particular use which exceed the aforestated obligation are
hereby disclaimed by Hameg be liable to buyer, in contract or in
tort, for any special, indirect, incidental or consequential dam-
ages, espresses, losses or delays however caused.
In case of any complaint, attach a tag to the instrument with a
description of the fault observed.
department, address and telephone number to ensure rapid ser-
vice.
The instrument should be returned in its original packaging for
maximum protection. We regret that transportation
due to poor packaging IS not covered by this warranty.
Maintenance
The most important characteristics
be periodically checked according th the instructions provided in
the sections "Operational check" and "Alignment procedcure".
To obtain the normal operating temperature,
with inserted module should
before starting the test. The specified alignment procedure
should be strictly observed.
When removing the case detach mains/line cord and any other
connected cables from case
Remove both screws on rear panel and, holding case firmly in
place, pull chassis forward out of case. When later replacing the
case, care should be taken to ensure that it properly fits under
the edges of the front and rear frames.
After removal of the two screws
chassis covers can be lifted. When reclosing the module, care
should be taken that the guides engage correctly with the front
chassis.
Operation of the module
Provided that all hints given in the operating instructions of the
I-NM 8001 Mainframe were followed —especially for the selec-
tion of the correct mains voltage —start of operation consists
practically of inserting the module into the right or left opening
of the mainframe. The following
observed :
Before exchanging the module,
switched off. A small circle (o) is now revealed on the red power
button in the front centre of the mainframe.
If the BNC sockets at the rear panel of the HM 8001 unitwere in
use before, the BNC cables should be disconnected
basic unit for safety reasons. Slide in the new module until the
end position is reached.
Before being locked in place, the cabinet Of the instrument is not
connected to the protective earth terminal (bananaplug above
the mainframe multipoint connector). In this case, no test signal
must be applied to the input terminals of the module.
Generally,the HM 8001 set must be turned on and in full operat-
ing condition, before applying any test signal. If a failure of the
measuring equipment is detected, no further measurements
should be performed. Before switching off the unit or exchang-
ing a module, the instrument must be disconnected from the
test circuit.
representation. agreement or
made by an agent, distributor.
Hameg employee. Hameg
Please supply name and
damage
of the instruments should
the mainframe
be turned on at least 60 minutes
of the mainframe HM8001.
at the rear of the module, both
precautions should
the mainframe must
from the
