5 Bulk Dump Request Format
5-1 One Memory Mixing Program Bulk Dump Data Format
STATUS 11110000
ID No. 01000011
SUB STATUS 0000xxxx
FORMAT No. 01111110
BYTE COUNT(HIGH) 00000110
BYTE COUNT(LOW) 00111010
01001100
01001101
00100000
00100000
00111000
01000001
00110100
00110001
DATA NAME 01001101
MEMORY NO. 0xxxxxxx
DATA*1 0xxxxxxx
0xxxxxxx
0xxxxxxx
0xxxxxxx
CHECK SUM*2 0xxxxxxx
EOX 11110111
5-2 All Program Change Assignment Table Bulk Dump Data Format
STATUS 11110000
ID No. 01000011
SUB STATUS 0000xxxx
FORMAT No. 01111110
BYTE COUNT(HIGH) 00000010
BYTE COUNT(LOW) 00001010
01001100
01001101
00100000
00100000
00111000
01000001
00110100
00110001
DATA NAME 01010000
MEMORY NO. 00100000
DATA*1 0xxxxxxx
0xxxxxxx
0xxxxxxx
0xxxxxxx
CHECK SUM*2 0xxxxxxx
EOX 11110111
F0 System Exclusive Message
43 Manufacturer's ID No. (YAMAHA)
0n n=0-15(Tx/Rx Channel No.)
7E Universal Bulk Dump
06 826(408x2+10)bytes
3A
4C 'L'
4D 'M'
20 ' '
20 ' '
38 '8'
41 'A'
34 '4'
31 '1'
4D 'M'
mm "mm=1(01h)-50(32h)...Scene Memory No.,"
127(7Fh)...Edit Buffer
dsH Scene Memory Data(408x2bytes)*3
dsL
: :
deH
deL
ee ee=(INVERT('L'+'M'+...+dsH+...+deL)+1) AND 7Fh
F7 End Of Exclusive
F0 System Exclusive Message
43 Manufacturer's ID No. (YAMAHA)
0n n=0-15(Tx/Rx Channel No.)
7E Universal Bulk Dump
02 266(128x2+10)bytes
0A
4C 'L'
4D 'M'
20 ' '
20 ' '
38 '8'
41 'A'
34 '4'
31 '1'
50 'P'
20 ' '
dsH Program Change Table(128x2bytes)*4
dsL
: :
deH
deL
ee ee=(INVERT('L'+'M'+...+dsH+...+deL)+1) AND 7Fh
F7 End Of Exclusive
