PREPARATION

FILTER INSTALLATION

To maintain the quality of the filters, they are installed in the main unit and packed in the
plastic bags. Be sure to remove the filters from the plastic bags before using the unit.
1
Remove the filters
Remove the Front Panel.
1
Push in the hooks, then pull
the Front Panel.
Pull out the Filter Frame and remove the Pre-Filter.
2
Filter Frame
Remove the HEPA Filter.
3
Preparing Active Carbon Filter.
Pre-Filter
HEPA Filter
Filter Frame
Remove the ActiveCarbonFilter(black) and HEPA Filter (white) from
4
the plastic bags.
Active Carbon Filter
Be sure to remove the power plug from the wall outlet.
Front Panel
Pre-Filter
Active Carbon Filter
HEPA Filter
E-6
Hook
(At open)
