Telegram Listing Standard
S3000/S300
8015792/YY12/2015-02-12
Subject to change without notice
Register name Block word
Speed data 6 ... 7
8
Error info 9
Field evaluation A 10
© SICK AG • Industrial Safety Systems • Germany • All rights reserved
Field bits Field name
11 Field D
12 Reset required
field A
13 Reset required
field B
14 Reset required
field C
15 Reset required
field D
0 ... 15 Speed inc 1
16 ... 31 Speed inc 2
0 Input E2
1 Input E1
2 ... 14 n/u
15 Speed status
0 ... 15 Error code
0 ... 5 Monitoring field
number
6 ... 7 Monitoring field
type
Field description
Intrusion detected by field
evaluation D.
0: Intrusion detected.
1: No intrusion detected.
Reset required by field
evaluation A.
0: No reset required.
1: Reset required.
Reset required by field
evaluation B.
0: No reset required.
1: Reset required.
Reset required by field
evaluation C.
0: No reset required.
1: Reset required.
Reset required by field
evaluation D.
0: No reset required.
1: Reset required.
Speed of Incremental
Encoder 1:
–2000 ... 2000 [cm/s]
(two's-complement
representation)
Speed of Incremental
Encoder 2:
–2000 ... 2000 [cm/s]
(two's-complement
representation)
0: Low
1: High
0: Low
1: High
n/u
Status of speed
0: The speed information
is invalid.
1: The speed information
is valid.
Lockout error or info code
0 ... 63: Monitoring field
number of field
assigned to field
evaluation A
0: Protective field
1: Warning field
2: Contour field
3: Inactive field. With the
inactive field selected
no monitoring field is
evaluated and the field
status is set as
configure with Expert
application
configuration block to
free (MutingField) or
intrusion (BlockingField)
83
