2.7

Picture appendix

The picture appendix is common for all the language versions. You can find it at the end of this manual in the Chapter Pictures.
1) Place for holding at the back (frame U-tube)
2) Side screen
3) Dismounted disc cover
4) Place for holding the machine at the front(cutting disc)
5) Tilted handlebars in the package (transport position)
6) Bag
7) Dismounted left and right disc cover
8) Middle cover (fixed-mounted to the machine)
9) Left cover
10) Right cover
Pict. 1: Unwrapping the machine
1) Disc drive clutch level
2) Wheel drive clutch lever
3) Handlebars fastening bolt
4) Accelerator lever (gas lever)
5) Side screen fastening bolt
6) Side screen
7) Cutting disc
8) Blades (4 pieces)
9) Disc cover according to the EN 12733 standard
10) Disc cover
11) Frame - tube
12) Handle
13) Engine
14) Fuel tank lid
15) Wheel
16) Gearbox cover
Pict.2: Description of the main parts
Position STOP:
Engine is not running (position '1')
➢
➢
➢
➢
Position MAX:
Engine is running at maximum rpm. (position „3"
hare)
➢
Pict. 3: Positions of accelerator lever
1) Upper disc
2) Blade
3) Bolt
4) Washer
5) Ring
6) Nut
Fig. 5: Mounting of cutting blade on the upper disc
Pict. 4: Cutting width
Pict. 7: Lubricating point
Pict. 6: Lubricating point
Pict. 13: Lubricating point
Pict. 8: Lubricating point
Pict. 9: Lubricating point
Pict. 10: Adjustment of the wheel drive tightening pulleys
Pict. 11: Disc drive clutch lever – brake
Used for turning off the running
engine.
Putting the machine out of service.
Refuelling
Machine transport
Working position
Position MIN:
Engine is running at idle. (position „2" turtle)
➢ Short work break
Position CHOKE:
Engine is running. (position „4")
➢ Cold engine start
BDR-620D
28
