3. INSTRUCTIONS FOR INSTALLATION
3.1. Before Installation
Before installing the heater, study the instructions
for installation. Check the following points:
Is the output and type of the heater suitable for
•
the sauna room? The cubic volumes given in
table 3 should be followed.
Is the supply voltage suitable for the heater?
•
If the house is heated by electricity, does the
•
pilot circuit (contactor) require a supplementary
relay to make the pilot function potentialfree,
because voltage control is transmitted from the
heater when it is switched on?
The location is suitable for the heater (see item
•
3.2. "Place and Safety Distances").
Note! Only one electrical heater may be installed
in the sauna room.
Heater
Output
Ofen
Leistung
Width/Breite
370 mm
Depth/Tiefe 370 mm
Height/Höhe
1200 mm
Weight/Gewicht
15 kg
Stones/Steine ca
kW
100 kg
PI70/PI70E
6,9
PI90/PI90E
9
Table 3.
Installation details of a PI/PI-E heater
Tabelle 3.
Montageinformationen zum PI/PI-E-Saunaofen
min. 1000 mm
360°
A/B/C
F
min. 500 mm
180°
A/B/C
F
G
Figure 5.
Safety distances
Abbildung 5. Sicherheitsmindestabstände
12
Sauna room
Connecting cable/Fuse
Saunakabine
Anschlusskabel/Sicherung
Cubic vol.
Height
400 V
Rauminhalt
Höhe
3N~
See item 2.3.
The measurements apply to the connecting
Siehe Kapitel
cable (fig. 6: B) only!
2.3.
Die Messungen beziehen sich
ausschließlich auf das Anschlusskabel
(Abb. 6: B)!
min.
max.
min.
m³
m³
mm
mm²
6
10
1900
5 x 1,5 3 x 10
8
14
1900
5 x 2,5 3 x 16
A
B
C
100 mm
min. 100 mm
D
min.
100 mm
E
DE
3. INSTALLATIONSANLEITUNG
3.1. Vor der Montage
Lesen Sie die Installationsanleitung, bevor Sie den
Saunaofen installieren. Überprüfen Sie die folgenden
Punkte:
Ist der zu montierende Saunaofen in Leistung
•
und Typ passend für die Saunakabine? Die
Rauminhaltswerte in Tabelle 3 dürfen weder
über noch unterschritten werden.
Ist die Netzspannung für den Saunaofen geeignet?
•
Falls das Haus elektrisch beheizt wird, benötigt
•
der Steuerkreis (Kontaktor) der Heizung ein Zwi-
schenrelais, um die Steuerfunktion auf potential-
frei zu stellen, da vom Saunaofen bei Gebrauch
eine Spannungssteuerung übertragen wird.
Der Standort ist für den Saunaofen geeignet
•
(siehe Kapitel 3.2. „Standort und Sicherheitsab-
stände").
Achtung! In einer Sauna darf nur ein Saunaofen
installiert werden.
Fuse
230 V
Fuse
Sicherung
1N~
Sicherung
A
mm²
A
3 x 6
1 x 35
3 x 10 1 x 40
A
C
Figure 6.
Cables
Abbildung 6. Kabel
Sensor cable
Data cable
Fühlerkabel
Datenkabel
Figure 6: D
Figure 6: C
Abb. 6: D
Abb. 6: C
mm²
mm²
4 x 0,25
6 x 0,5
4 x 0,25
6 x 0,5
D
B
