LASER LEVEL

OPERATION

Place the laser level on a firm and stable surface or a tripod. Move
the switch bar to select required operating mode:
1) Locked pendulum for projection of inclined lines and planes:
Move the switch bar to OFF position. Pendulum is locked. Press
to switch on the device.
To switch off the laser level press and hold
2) Automatic levelling for building horizontal and vertical lines and
planes:
Move the switch bar to ON position. Pendulum is unlocked. If the
laser level is out of the range of automatic levelling laser lines will
flash.
To switch off the laser level move the switch bar to OFF position.
3) Pulse mode:
Pulse mode is switched on automatically when medium and low laser
line brightness is set.
Attention! To increase the operating time and avoid the risk of
unintentional blinding adjust brightness of laser emitters.
If operated near objects or airflows different from the environment
temperature the laser line may tremble due to heterogeneity of the
atmosphere. The longer the distance, the more trembling can be
observed.
The width of the laser line increases with the increasing of the
operating distance. The marking should be made along the axis of the
laser line. For maximum accuracy, use the middle portion of the laser
line.
It should be noted that the shape of the laser line on the object's
surface (e.g. walls, ceilings) depends on the curvature and slope of
the surface relative to the laser plane.
CONDTROL SMART 2D Plus
user manual
for 2 seconds.
