The station is in calibration mode.
The +/- keys must now be used to enter the measured value.
Press the 2 CONFIRM button to confirm the value.
If the measured temperature still differs from the temperature shown on the
display, the process must be repeated.

2.8. Tip / Filter / Heatingelement

2.8.1 Tip
• Switch on the soldering station and heat the solder to melting
temperature.
• Remove oxides from the soldering tip
• Clean the soldering tip with the included cleaning tool.
• Wet the soldering tip with fresh solder.
NOTE: The soldering tip should always be selected according to the application.
Otherwise, the service life of the soldering tip will be reduced or the soldering
tip function will be limited.
A B
0,8 2,3
1,0 2,5
1,3 3,0
1,6 3,0
