• After switching off, wait until the heated parts have reached room temperature if
you want to touch them or change parts of them.
• Make sure that the device and the shelf are secure. Place the tool on the shelf
when not in use.
• The use of the device by children from 8 years and persons with disabilities is
possible if they are supervised and instructed for safe use.
• Power supply cables must not come into contact with sharp edges, heat or oils.
Damaged connection cables must be replaced by customer service to prevent
potential hazards such as electric shock, short circuits or fire.
• The device must only be operated at the rated voltage and frequency specified
on the device. Use only supplied earthing contact connecting cables.
• Before use, check the device for damage and the correct fit of the soldering tip.
If damage is detected, it must be switched off. Then please contact the
customer service.
• Use only Quick Original replacement parts.
• When not in use, keep the device away from dust and moisture.
• Pay attention to the respective safety, health and safety regulations.

2.2. Application

The QUTV2 can be used for melting and removing solder. The solder is heated and
melted with the soldering tip. The liquid solder is sucked out into the flask with a
vacuum. THT components can thus be removed from the assembly effectively and
quickly. In addition, the device can be used to remove residual solder. Thanks to the
high-frequency eddy current heating, the device is ready for use within a few
seconds.

2.3. Properties

• LCD-Display
• Touch control panel
• Modern design
• Powerful vacuum pump
• Temperature Calibration Function
• Number of desoldering operations are counted.
CAUTION
Measures for a safe working environment:
