The receiver features additional facilities for controlling
the display. We considered it important to keep the unit's
front panel compact, easy to understand and easy to use,
and since these functions are seldom needed, they do
not have their own button.
The display functions are grouped together in a menu.
To call up the menu which offers the display control
facilities, simply hold the 
about a second.
The screen shows the first menu point:
'
INP LEVEL INP LEVEL
INP LEVEL INP LEVEL
Press the   or   button briefly to cycle
   
through the four menu points in the display:
'
INP LEVEL INP LEVEL INP LEVEL INP LEVEL
'
DISP NORM DISP NORM DISP NORM DISP NORM
'
DISP SOFT DISP SOFT
DISP SOFT DISP SOFT
'
DISP OFF DISP OFF DISP OFF DISP OFF
The meaning of the four display functions is explained in
the next section.
When you wish to activate the menu point which
•
actually appears on the screen, hold the 
button pressed in for about a second until the word
' ' appears on the screen. The facility you have
SET SET
SET SET
selected is now switched on.
You may want to interrupt the menu system without
•
activating a menu point (i.e. without changing any-
thing). To do this simply tap the 
The receiver then returns to the normal display with-
out making any changes.

Display functions

 button pressed in for
 
'
'
'
'
'
  
 button briefly.
 
"INP LEVEL" = field strength display
It can be very useful to have an accurate display of signal
field strength; particularly when setting up a rotary
antenna. The receiver provides a highly accurate and
finely graduated field strength display facility.
When you call up this function, the display first switches
to normal brightness, regardless of the previously set
brightness.
Next you will see an '
(instead of the preset number or tuning indicator),
followed by a numerical value.
The display range is 0 ... 25. When you have finished
with the field strength display you can return to the
normal screen at any time by tapping the 
briefly.
"DISP NORM / DISP SOFT / DISP OFF"
Adjustment of display brightness
The brightness of the receiver 's screen can be adjusted
to suit your personal preference. Three levels are
available:
1. Normal setting:
Good legibility even in daylight and sunshine
2. Darkened:
Restrained setting, for locations with subdued lighting
3. Display switched off:
The display is completely switched off
If brightness level 2 or 3 is selected, the display is acti-
vated and switched to normal brightness briefly every
time you operate a control. This makes it possible to
check the settings even from a distance.
After about 4 seconds the screen switches back auto-
matically to the selected brightness value. One effect of
this arrangement is that a newly selected brightness
value only becomes effective after a delay of about 4
seconds.
32
' (Level) on the left of the screen
L L L L
 button
 
"DISP NORM"
"DISP SOFT"
"DISP OFF"
