Electrical connection
6. Electrical connection
6.1
General instructions for electrical installation
Ensure that the electrical installation complies with the technical standards and regulations
applicable in your country.
The IR radiator and the control unit must be connected in accordance with the wiring diagrams.
Observe the installation and operating instructions for the control unit.
See also Chapter 4: Technical data
6.2

Internal wiring

230V/50Hz
L
NOTICE
Material damage due to short circuiting
An excessive load can overload and damage the control unit.
When connecting, observe the maximum permissible load of the outputs in the
ƒ
control unit! Observe the installation and operating instructions for the control unit!
N
3 x 1,5²
S1
Dimmer
IR-Emitter
41
