7. First insert the back panel into the
prepared opening. Insert the IR radiator
into the previously inserted back panel
so that the fastening holes of the IR
radiator match the fastening holes of
the back panel. Then attach the back of
the radiator to the cabin wall using the
enclosed chipboard screws.
Note: The cable connection must be
facing downwards.
8. Finally, attach the cover to the housing
with 2 screws at the top and bottom.
Important: Do not install the IR radiator in the
direct range of another radiator, otherwise it
may be damaged.
Do not cover the area facing forwards above
the radiator with wood. This can cause heat
accumulation.
Do not expose the emitter to mechanical
loads (shocks, pressure, falls). Danger of
breakage!
