Symbols on the device
(according to type of appliance)
Risk of burns, surface of appli-
ance becomes hot during opera-
tion
Risk of scalding from steam
Read the operating instructions
USE WATER ONLY Only fill water without additives
into the water reservoir
Pressure controller
The pressure controller keeps the pressure in the steam
boiler as constant as possible during operation. The
heating is switched off when the maximum operating
pressure is reached in the steam boiler and is activated
if there is a pressure drop in the steam boiler as a result
of a steam removal.
Safety thermostat
The safety thermostat prevents the device from over-
heating. If the pressure regulator and the boiler thermo-
stat fail and the unit overheats, the safety thermostat
switches the unit off. Before resetting of the safety ther-
mostat, contact the responsible KÄRCHER Customer
Service.
Boiler thermostat
The boiler thermostat switches off the heating in the event
of a fault; for example, if there is no water in the steam boil-
er and the temperature in the steam boiler rises.
As soon as you refill the water, the device is ready for
use again.
Maintenance lock
The maintenance lock seals the steam boiler from the
steam pressure present. The maintenance cap is also a
pressure relief valve. If the pressure regulator is defec-
tive and the steam pressure in the steam boiler rises,
the pressure relief valve opens and steam is escapes
through the lock.
Prior to restarting the device, contact the responsible
KÄRCHER Customer Service.
Device description
The maximum amount of equipment is described in
these operating instructions. Depending on the model,
there are differences in the scope of delivery (see pack-
aging).
For the illustrations, refer to the graphics page.
Illustration A
Device socket with cover
1
Water reservoir
2
Carrying handle for water reservoir
3
Selector switch
4
Control panel
5
Display - OFF position
6
Display - water shortage (red)
7
Display - heating (green)
8
Steam stage 1
9
Steam stage 2
10
Steam stage 3
11
Steam stage 4
12
VapoHydro function steam stage
13
Display - iron detection
14
Display - steam gun detection
15
Cap for accessory compartment
16
Maintenance lock
17
Carrying handle
18
Holder for accessories
19
Accessory storage compartment
20
Mains connection cable storage compartment
21
Park bracket for floor nozzle
22
Mains connection cable with mains plug
23
Non-driven wheels (2 x)
24
Steering roller
25
Steam gun
26
Steam lever
27
Unlocking button
28
Child lock
29
Steam hose
30
Steam connector
31
Extension tubes (2 x)
32
Unlocking button
33
Floor nozzle
34
Hook and loop fastener
35
Floor cleaning cloth (2 pieces)
36
** Carpet glider
37
** XXL crevice brush
38
Hand nozzle
39
Microfiber cover for hand nozzle
40
Spot jet nozzle
41
Round brush (small, black)
42
** Round brush (small, yellow)
43
** Power nozzle
44
** Round brush (large)
45
** Comfort window nozzle
46
Descaler
47
** Steam pressure iron
48
Indicator light (orange) - heating
49
Steam switch (bottom)
50
Steam connector
51
** optional
