UNPACK YOUR CEILING FAN
WARNING: Keep packaging materials out of the reach of
children. Never allow children to play with the packaging.
Open the original carton and verify the following items.
If there are any missing or damage items, contact customer
service. Do not throw away the carton or other packaging material
as it may be needed for warranty replacement or repair.
Module Motor parts:
- Fixation plate
- Canopy and canopy cover
- Ball and a rod of 10 Cm
- A downrod of 25 Cm
- A signal receiver
- A remote control with its wall holder
- A motor with its decorative cover
- A motor cover bracket in painted or chromed aluminum
- An aluminium cover in the color of the motor or blades
- Engine mounting kit
- Balancing kit
The Blades:
- 3 Blades
- 9 screws to connect the blades and the motor
- Two adapters for 2-blades mounting (only
- 4 screws for the adapters (only
The Light Kits:
- A light kit support which can be placed on the lower part of the fan
using 3 screws.
- A LED light kit placed on the previous support.
P1, P2, P4
)
P1, P2, P4
