Product description
‰ When transporting the product is to be secured in accord-
ance with the provisions of the transportation aid used.
‰ Only hoists and slings must be used for for transporta-
tion, which are dimensioned so that they can take safe
loading, unloading and installing of the product occurring
forces.
‰ As a stop-and lifting points only defined for the points on
the pallet and the product may be used.
‰ Are working under the raised parts or equipment re-
quired, they must be secured with suitable devices to pre-
vent falling. Work equipment for lifting loads must prevent
the load from accidentally shifting or dropping in free fall
or being hooked unattended.
‰ Staying under suspended loads is prohibited.
‰ A protective helmet should be worn during loading and
unloading with suitable lifting gear.
‰ Assembly and installation work must always be per-
formed only by qualified and trained personnel.
‰ The rated torque and rated duration must be compatible
with the characteristics of the driven member ("Hanging").
‰ With the RolTop/D+ Type M is the smallest inner pipe
diameter for the winding shaft 47 mm.
‰ Access to the drive must be possible through a freely
accessible and always with little effort to open access
panel, which should be sufficiently large.
3.8
Safety instructions for operation
‰ The user of the product is required to satisfy themselves
prior to the first use of the safe and proper condition of
the product.
‰ That is necessary also during the operation of the product
at regular time intervals which can be specified by the
operator.
3.9
Safety instructions for electrical installation
‰ All work on the electrical system of the plant may only
be used by qualified electricians in accordance with the
applicable rules and regulations of the trade association,
to be made in particular as per the requirements of DIN
VDE 0100. Furthermore, the national law of the country
of use are to be observed.
‰ In case of defects, such as loose connections or defec-
tive or damaged cables to the system, the product must
not be put into operation.
‰ Prior to inspection, assembly and disassembly, the sys-
tem (roller shutter, roller blind) is disconnected from the
mains.
‰ All electrical connections, safety devices, fuses, etc. must
be properly installed, connected and grounded.
‰ The provided power connection must be designed as
specified in the wiring diagram (voltage, voltage level).
‰ A line protection switch (circuit breaker) is sufficient to
separate the plant from the grid (and if only one phase
and zero is used).
‰ If a fixed (permanently installed) drive is not equipped
with a power cord with a plug or with other means for dis-
connection from the mains, which at each pole a contact
opening under the conditions of overvoltage category
III (according to IEC 60664-1) for full separation, as a
disconnecting device must be installed in the fixed wiring
according to the regulations.
‰ The mains connection cable for drives with a rubber
hose, (abbreviation 60245 IEC 53) may be replaced only
with the same line type.
4 | EN
‰ For drives where after installation the access to unpro-
tected moving parts is possible, the following applies:
Moving parts of the drive must be mounted more than 2.5
meters above the ground (or any other level which pro-
vides access to the drive).
4
Product description
The RolTop/D+ is an electromechanical tubular motor drive.
It performs parallel axial movements.
‰ Elero cable assembly is not required to start up the Rol-
Top/D+. The elero assembly cable serves if necessary
only for the deletion of the end positions and/or for restor-
ing the delivery status..
‰ Sunblind with free ride
‰ The RolTop/D+ requires top and bottom fixed anchor
points. This is how an Automatic recognition and learning
of the end positions (self-learning) works.
‰ Automatic correction of the final position, for example by
installing a window sill.
►The use of rigid shaft connectors and plugs stop or angle
strips or covert attacks is a prerequisite.
►The height of the curtain is adjusted so that the push-up
protection operates correctly.
►For this purpose observe the requirements of the roller
shutter manufacturer.
• The variant-dependent values of your RolTop/D+ can be
removed from the type label.
• The different versions of the RolTop/D+ contain different
types of brake systems depending on size and torque.
The result may yield different performance eg regarding
access to end positions.
5
Assembly
Personal injury from hot surfaces.
Drive heats up during operation, the drive housing can be
hot. Possible burning of the skin.
►Wear personal protective equipment (gloves).
Triggered by a possible material errors may occur or
impact shock and injury due to a gearbox break, bud break
or a clutch defect.
►Suitable materials are to be used for the construction as
well as perform a sampling inspection by double load test
according to DIN EN 60335-2-97.
Risk of injury due to impact or shock caused by not properly
mounted or latched motor bearings. Hazards caused by
insufficient stability or stability and stored energy (gravity).
►Selection of engine bearing torque specifications.
►Drive must be backed up with all attached backup de-
vices.
►Check for proper latching on engine mounts and correct
tightening torques.
Danger of injury due to electric current.
Electric shock possible.
►Electrical work can only be performed by an authorized
electrician.
Danger of injury due to electric current.
© elero GmbH
CAUTION
WARNING
