Table of contents
1 Introduction ........................................................
2 Product description (Fig. 1) ................................
3 Scope of delivery (Fig. 1) ...................................
4 Proper use..........................................................
5 Safety instructions..............................................
6 Technical data....................................................
7 Unpacking ..........................................................
8 Before commissioning........................................
9 Operation ...........................................................
10 Working instructions...........................................
11 Cleaning .............................................................
12 Maintenance.......................................................
13 Storage and transport ........................................
14 Repair and ordering spare parts ........................
15 Disposal and recycling .......................................
16 Troubleshooting .................................................
17 EU Declaration of Conformity.............................
18 Exploded view ....................................................
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Before com-
missioning,
read and ob-
serve the oper-
ating manual
and safety in-
structions!
Attention! Fail-
ure to observe
the safety
signs and
warning infor-
mation affixed
to the product
and failure to
observe the
safety and op-
erating manual
can result in
serious injury
or even death.
Wear safety
goggles.
Wear hearing
protection.
18 | GB
18
19
19
19
20
22
23
23
25
26
26
27
28
28
28
29
30
44
Do not use the
product one-
handed.
Cordless prun-
ing saw must
be placed up-
right!
Do not lie
down!
1
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Oil tank con-
Importer:
tents.
Ankara Civata Hırdavat Bağlantı Elemanları İthalat
İhracat Sanayi ve Ticaret A.Ş.
Weight kg.
Macun Mahallesi 250. Cadde No:26
Yenimahalle/Ankara/Türkiye
www.scheppach.com
Always wear a
safety helmet!
Wear safety
gloves!
Wear sturdy
footwear!
It is important
to wear protec-
tive clothing for
hands, fore-
arms, legs and
feet.
Filling port for
chain oil
Installation di-
rection of the
90
saw chain
Do not expose
the product to
rain. The prod-
uct may only
be stationed,
stored and op-
erated in dry
ambient condi-
tions.
Always hold
the product
firmly with both
hands.
Introduction
Blade length
Cutting length
Warning! Risk
of kick-back.
Beware of the
kick-back of
the product
and avoid mak-
ing contact with
the rail tip.
Only carry out
maintenance,
modification,
adjustment and
cleaning work
when the motor
is switched off
and the battery
is removed.
Switch lock
Guaranteed
sound power
level of the
product.
Lithium-ion bat-
tery
The product
complies with
the applicable
European di-
rectives.
