Part2 Installing Your Front Wheel & Seat Pack
1
Turn the bike over so the front
fork faces up and install the
front wheel make sure disc
(
rotors from the front and rear
wheels are on the same side
!
To prevent the computer display
from being damaged, position it so
it does not come into contact with
the floor.
The disc head
rotor must nut
fit inside the
disc brake
1
perfectly.
2
Place bolts and springs in the order shown.
handle can be on either side.
before firmly securing the lever handle.
.
)
spring spring nut lever
handle
2 3 4 5
The lever
(
Twist on the head nut
)
ASSEMBLY GUIDE | CYRUSHER RUMBLE
4
Insert the seat post into
the frame, adjusting it
according to your height.
!
The maximum position to which
the seat post can be pulled up
should not exceed the top limit
graduation line to prevent the
frame tube from breaking and
injuring cyclists.
