2. Ensure that the sliding blocks underneath the wing
screws of the parallel stop (15) are properly en-
gaged in the grooves of the base plate.
3. Move the parallel stop (16) to the desired position
and tighten the wing screws of the parallel stop
(15) firmly.
8.3 Assembling the chuck guard (fig. 2)
1. Insert the chuck guard (13) into the holes provided
in the machine frame.
2. Secure the chuck guard (13) by hand-tightening
the screws (C).
8.4 Assembling the handle (fig. 2)
1. Remove the pre-mounted fastening screw (B).
2. Slide the spacer sleeve (K) and the handle (8)
onto the mount (D), as shown in Fig. 2.
3. Tighten the blade fastening screw (B) firmly.
8.5 Assembling the clamping lever for depth stop
(fig. 2)
Assemble the clamping lever for depth stop (6) as
shown in fig. 2.
8.6 Fastening to a work surface (fig. 3)
Fasten the device to the work surface by bolting the
base plate (1) to the work surface.
9. Operation
9.1 Operation of the display (fig. 4)
• Switching the display on/off:
Press the button (I, 2-3 sec.) until the display (9) switch-
es on or off.
• Adjusting the oscillation rate
• Press the button to increase the oscillation rate
(fig. 12.1).
• Press the button to decrease the oscillation rate
(fig. 12.2).
• Switching the laser cross on/off:
The laser cross can be switched on or off by pressing
the button (12.3).
9.2 Height adjustment (fig. 1)
The position of the machine head can be adjusted to
suit the workpiece height or the workpiece length.
1. Hold the handle (8) firmly.
2. Release the clamping lever for the height adjust-
ment (5).
3. Set the position of the machine head with the han-
dle (8).
30 | GB
4. Secure the position of the machine head with the
height adjustment clamping lever (5).
Attention! Ensure in the lowest machine head position
that the machine head will not be moved beyond the
marking.
Use the clamping lever for height adjustment (5) to se-
cure the machine head in this position. Otherwise, the
guide could be damaged.
9.3 Setting the drilling depth (fig. 1, 11)
The drilling depth can be set with the depth stop (7).
1. Release the clamping lever on the depth stop (6).
2. Carry out a test drilling. As soon as the desired
depth, tighten the depth stop clamping lever (6)
again.
3. The depth stop (7) is now locked in the desired
drilling depth.
4. Then check the position of the depth stop. If
necessary, loosen the pointer (18) with a Phillips
screwdriver, set the scale (20) to 0° position and
re-tighten the retaining screw (19).
9.4 Clamping/releasing drill bits (fig. 4, 7)
Caution! Always release the chuck key. Risk of in-
jury due to chuck key being thrown away!
9.4.1 Clamping
1. Fold the tension chuck guard (13) upwards.
2. Insert the chuck key (G).
3. Turn the chuck key (G) counterclockwise, to open
the clamping sleeve (E).
4. Insert the insertion tool (F).
5. Hold the insertion tool (F) firmly.
6. Turn the chuck key (G) clockwise, to close the
clamping sleeve (E) and to secure the insertion tool.
7. Check that the insertion tool (F) is tightly fitted.
8. Pull the chuck key (G) apart.
9.4.2 Releasing:
1. Fold the tension chuck guard (13) upwards.
2. Insert the chuck key (G).
3. Turn the clamping sleeve (G) clockwise until the
installation tool (F) can be removed.
4. Pull the chuck key (G) apart.
