Features of fiber transmission modules
MULTIMODE TRANSMISSION MODULE
Data transmission
Type:
Type of interface:
Cable length (max.)
Multimode 62.5/125 μm,
Class OM1:
Multimode 50.0/125 μm,
Class OM2:
Multimode 50.0/125 μm,
Class OM3:
Performance data
Wavelength(λ):
Optical power output (P
in 50 oder 62,5 μm MMF:
Receiving sensitivity (P
Sensitivity – Stressed (P
SINGLEMODE (S) TRANSMISSION MODULE
Data transmission
Type:
Type of interface:
Cable length (max.)
Singlemode 9/125μm,
Class OS1:
Performance data
Wavelength(λ):
Optical power output (P
in 9 μm SMF:
Receiving sensitivity (P
SINGLEMODE (S+) TRANSMISSION MODULE
Data transmission
Type:
Type of interface:
Cable length (max.)
Singlemode 9/125μm,
Class OS1:
Performance data
Wavelength(λ):
Optical power output (P
in 9 μm SMF:
Receiving sensitivity (P
Optical fibres (2 fibres)
LC duplex
100 meters
200 meters
400 meters
850 nm (830 nm bis 860 nm)
)
-9,0 dBm bis -2,5 dBm
OUT
):
-15 dBm (OMA)
MIN
138μW (50 μm MMF)
):
S
Optical fibres (2 fibres)
LC duplex
5 Kilometer
1310 nm (1260 nm bis 1350 nm)
)
-9,5 dBm bis -3,0 dBm
OUT
):
-18 dBm (OMA)
MIN
Optical fibres (2 fibres)
LC duplex
10 Kilometer
1310 nm (1260 nm bis 1360 nm)
)
-8,4 dBm bis -1,0 dBm
OUT
):
-18 dBm (OMA)
MIN
G&D ControlCenter-Compact · 29
Technical data
