Matrix switch »ControlCenter-Compact«

A KVM matrix system consists of at least one central module, one console module

or DynamicWorkplace-CON (DWC) and one computer module.

The central module of the ControlCenter-Compact series is the central device of the

KVM matrix system. Console modules, DWCs and computer modules, are

connected to the central module.

NOTE:

You can use the KVM matrix system to access a computer module with a

console module or with a DWC. By accessing the computer connected to the

computer module, the video image is displayed at the console monitor or the

DWC monitors.

You can now operate the accessed computer with console/DWC keyboard and

console/DWC mouse.

The ControlCenter-Compact series includes the following variants:

Variant

ControlCenter-Compact-8C

ControlCenter-Compact-16C

ControlCenter-Compact-16F

ControlCenter-Compact-16F16C

ControlCenter-Compact-32C

ControlCenter-Compact-32F

ControlCenter-Compact-32F-16C

ControlCenter-Compact-32F-32C

ControlCenter-Compact-32F-48C

ControlCenter-Compact-32F-80C

ControlCenter-Compact-48C

ControlCenter-Compact-48F

Matrix switch »ControlCenter-Compact«

Dynamic ports to connect modules

8 × RJ45 socket (CAT)

16 × RJ45 socket (CAT)

16 × LC duplex socket (Fiber,
