BEHNCKE Level Control / How the hanging electrodes work
Permission
Service menu
settings
Set
clock
Configure
system
Configure dry run protection
The filter pump is switched off when
the probe falls below H2.
Configure manual backflush input
Set whether backflushing or lowering
of the tank level should be carried out
via this input.
13
Enter code
:
Time:
:
¥:minutes/OK
±
Date
s/month
Calibrate clock
Automatic:
Sum./wint. time
Pool type
floor valve
Configure
Release:
filter pump
Level adjustment
Delay:
Level adjustment
Max:
Level adjustment
Configure
Delay:
dry run protect.
Dry run protect.
Release:
via floor valve
MBF input
CR output
Configure
Release:
filter cleaning
via HE6
Delay:
via HE6
Release:
floor valve
Forced activ.:
Channel circ.
Configure
Delay:
lowering
MBF input
Max:
lowering time
Configure prog.
Release:
output 1
by filter pump
Delay:
prog. output 1
Filling valve
Configure
Delay:
refilling
refilling
DT output
Configure
collect. flt. msg
Enable additional permissions
You can enable additional settings menu items
(highlighted in orange) here. The password for the craftsman
level can be found in the enclosed note for system installers.
Set the time
Set the system time
Set the date
Set the date. Press "OK" to continue to the next input field.
Calibrate timer
A compensation value can be set in 20 second increments if
the time of day deviates continuously.
Automatic summer/winter time
Set whether to switch automatically between summer and
winter time.
Set the pool type
Here you can switch between "with channel" and
"with skimmer".
Configure the floor valve
Here you can switch between "available" and "not available".
Flow switch installed
Here you can switch between "yes" and "no".
Level adjustment delay
Time until level compensation is switched on.
Setting range: 0s - 60s
mins
Maximum level compensation runtime
Maximum runtime of the filter pump with active level compensation.
Setting range: 0 - 180 mins.
s
Dry run protection delay
Time until level compensation is switched on.
Setting range: 0 - 600s.
Type of flow switch
Here you can switch between "normally open contact"
and "normally closed contact".
Configure the floor valve
Here you can switch between "backflushing" and "lowering".
Clear rinse function output
Here, it is possible to switch between "rinsing" (standard
rinse function), "prog. output 1" (programmable output) and
"lowering".
Enable HE6
Setting for activating backflushing when probe H6 is reached
s
Filter cleaning delay
Time to switch on filter cleaning.
Setting range: 0 - 60s.
Enable floor valve
Setting for extraction via the floor drain (if available) during
backflushing.
Forced activation of channel circulation
mins
If backflushing takes place outside the specified filter runtime,
the duration of the subsequent filtration operation can be defined here.
s
Lowering delay
Time until filter cleaning is turned on.
Setting range: 0 - 60s.
mins
Maximum lowering runtime
Set the maximum permissible runtime for the lowering runtime.
Setting range: 1 - 60min.
Enable programmable output 1
Here you can switch between "Yes" and "No".
s
Programmable output 1 delay
Time to send signal.
Setting range: 0 - 60s.
Configure filling valve
Sets whether a filling valve is connected.
s
Refilling delay
Set the delay time until the refilling begins when the probe
H falls below the probe H3.
Dispensing technology output
The dispensing technology clip can fulfil 4 different functions:
"Dispensing technology output DT", "backflushing output DT",
"Programmable output 2 DT" or "Lowering DT"
Configuring central fault messages
Set which events trigger a central fault message
