BEHNCKE Level Control / How the hanging electrodes work
6
How the hanging electrodes work
H5
H4
H3
H2
H1
In the Normal operating mode, the water level oscillates between the probes H3 and H4.
The switching distances between the electrodes should be at least 5 cm.
The maximum length of the probe is 30m.
11
Status display
H6
H5
H4
H3
H2
H6
DANGER
The installation and connection for the fresh water for refilling when drinking
water is used in accordance with DIN EN 1717 and DIN 1988 or other national
regulations. Ensure that a safety overflow of adequate size is available and
connected to the wastewater pipe.
LED H6 ON
LED H5 ON
LED H4 ON
LED H3 OFF / H4 ON (flashing)
LED H2 and H3 ON
Forced backflushing ON
This function can be switched on and off in the
"Configure system" menu under Filter cleaning.
Forced activation, pump ON
This function can be switched on and off in the menu
"Configure system" under "Conf. filter pump".
Forced activation OFF, Solenoid valve CLOSED
The MV can be switched on and off in the menu
"Configure system" under "Filling valve available".
Solenoid valve OPEN, dry run protection: Pump ON
In the menu "Conf. system" under "Conf. refilling" you have the
option to enter a response delay time from the MV
Dry run protection, pump OFF
In the menu Parameters under "Adjust refilling" you have the
option of setting "Max. runtime", "Max. daily runtime" and a start
and stop time!
Dimensions
